TPR - Thermoplastic Rubber (DK) Casters

model: CST-F34-6X2DK-SWB

Featured Casters & Wheels

High Quality Nylon

Cast Iron/ Semi-Steel Casters

Polyurethane (SI) Casters

Cast Iron/ Semi-Steel Casters

Japanese Engineered Spring Loaded Towing Casters

TPR - Thermoplatic Rubber (DK) Casters

High Quality Non-Marking Solid Rubber

Heavy Duty Polyurethane Casters

Phenolic Wheel

model chart

Product Family Overview

Print Friendly

TPR - Thermoplastic Rubber (DK) Casters

SERIES: CST-F34-DK

Made of high-tech thermoplastic rubber, TPR (DK). Gray tread color. 65 Shore A. Wheel core is constructed of polyolefin. Made in Taiwan

Non-Marking High-Grade Proprietary Tread
Rejects Debris (including metal shavings)
Smooth Ride/Performance
Exceptional Floor Preservation
Impact Resistant
Resists Most Solvents, Oils, Grease, and Water

Made of high-tech thermoplastic rubber, TPR (DK). Gray tread color. 65 Shore A. Wheel core is constructed of polyolefin. Made in Taiwan

Non-Marking High-Grade Proprietary Tread
Rejects Debris (including metal shavings)
Smooth Ride/Performance
Exceptional Floor Preservation
Impact Resistant
Resists Most Solvents, Oils, Grease, and Water

Other "Go-To" Casters

Polyurethane (SI - Electrostatic Dissipating) Casters

High-Temp Phenolic Casters

Poly On Poly Casters (Orange)

TPR(Thermoplastic Rubber) On Stainless Steel Casters

Follow @vestilmfg

Additional Models In This Family
view entire Image Gallery

CST-F34-4X2DK-SWB

CST-F34-6X2DK-S

CST-F34-8X2DK-R

CST-F34-5X2DK-R

CST-F34-4X2DK-SWB

CST-F34-8X2DK-SWB

CST-F34-5X2DK-SWTB1

CST-F34-6X2DK-R

CST-F34-5X2DK-SWB

CST-F34-8X2DK-R

CST-F34-6X2DK-R

CST-F34-8X2DK-S

CST-F34-4X2DK-R

CST-F34-8X2DK-S

model chart

Model Specific Details

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.

The Search Box below is for Casters within the Model Chart on this page. Not an entire site search.

Model	PDFs	Caster Size	Type	Capacity (lbs.)	Overall Height	Top Plate Size	Net Wt. (lbs)
CST-F34-4X2DK-R	1 YEAR Limited Warranty	4 x 2	RIGID	450	5-1/2	4 x 4-1/2	4
CST-F34-5X2DK-R	1 YEAR Limited Warranty	5 x 2	RIGID	500	6-1/2	4 x 4-1/2	4
CST-F34-6X2DK-R	1 YEAR Limited Warranty	6 x 2	RIGID	600	7-1/2	4 x 4-1/2	5
CST-F34-8X2DK-R	1 YEAR Limited Warranty	8 x 2	RIGID	675	9-1/2	4 x 4-1/2	5
CST-F34-4X2DK-S	1 YEAR Limited Warranty	4 x 2	SWIVEL	450	5-1/2	4 x 4-1/2	4
CST-F34-5X2DK-S	1 YEAR Limited Warranty	5 x 2	SWIVEL	500	6-1/2	4 x 4-1/2	5
CST-F34-6X2DK-S	1 YEAR Limited Warranty	6 x 2	SWIVEL	600	7-1/2	4 x 4-1/2	6
CST-F34-8X2DK-S	1 YEAR Limited Warranty	8 x 2	SWIVEL	675	9-1/2	4 x 4-1/2	6
CST-F34-4X2DK-SWB	1 YEAR Limited Warranty	4 x 2	SWIVEL W/BRAKE	450	5-1/2	4 x 4-1/2	5
CST-F34-4X2DK-SWTB1	1 YEAR Limited Warranty	4 x 2	Swivel w/brake	450	5-1/2	4 x 4-1/2	5
CST-F34-5X2DK-SWB	1 YEAR Limited Warranty	5 x 2	SWIVEL W/BRAKE	500	6-1/2	4 x 4-1/2	5
CST-F34-6X2DK-SWB	1 YEAR Limited Warranty	6 x 2	SWIVEL W/BRAKE	600	7-1/2	4 x 4-1/2	6
CST-F34-8X2DK-SWB	1 YEAR Limited Warranty	8 x 2	SWIVEL W/BRAKE	675	9-3/8	4 x 4-1/2	7
CST-F34-5X2DK-SWTB1	1 YEAR Limited Warranty	5 x 2	Swivel w/Total Brake	500	6-1/2	4 x 4-1/2	6
CST-F34-6X2DK-SWTB1	1 YEAR Limited Warranty	6 x 2	Swivel w/Total Brake	600	7-1/2	4 x 4-1/2	6
CST-F34-8X2DK-SWTB1	1 YEAR Limited Warranty	8 x 2	Swivel w/Total Brake	675	9-1/2	4 x 4-1/2	7
